Parameters
| Attribute | Technical Data |
|---|---|
| Power: | 220v,50hz,01 Phase |
| Driver: | Yako 750W AC servo driver |
| Sensors: | Omron, Japan |
| Spindle: | HQD 6 kw, Air Cooling |
| Inverter: | Best 7.5 kw |
| Motor Power: | Yako 750W AC servo motor |
| Table Height: | Standard |
| Control Cabinet: | Independent |
| Control System: | DSP Richauto A11E |
| Travelling Size: | 2500*1400*300mm |
| Lubrication System: | Manual Lubrication Pump |
| Electric Components: | Schneider |
| Z Transmission System: | TBI Ball Screw with Coupling Structure |
| Working Table Structure: | T-slot table + White PVC (Pasted on the aluminium table) |
| X, Y Transmission System: | RACK AN PINION 1.5M |
| Linear Guide Way and Block: | 25mm Hiwin guide rail |
