| Sensor | Original Omron Brand with Manual Lubrication Pump |
| Z Axis | Ball Screw, Connection as Coupling Type |
| Spindle | Air Cooling Spindle 4.5 KW for 220V & 6.0 KW for 380 V |
| Inverter | Fuling 5.5 KW for 220 V & 7.5 for 380 V |
| X, Y Axis | 25 MM Taiwan Shac Brand Liner Guidway and Block J&T Brand 1.5 M Hilical Rack |
| Table Height | 750 mm |
| Control System | DSP System (Weihong) |
| Dust Collector | 2.2 Kw for 220V & 3.0 Kw for 380 V Dust Collector |
| Spindle Speed | 18000 rpm |
| Working Table | Manual Clamping, Aluminum Bar With White PVC Strip Thickness 12 mm |
| Z Axis Driving | Servo Motor With Braking system |
| Travelling Size | 2500*1300*300 MM |
| Electronic Components | AC Contactor, Circuit Braker and Switch Power Supply From Schneider Brand |
| X,Y Axis Driving System | Servo Motor |
